HVC 320W LED Driver

HVC-320W-56A,B,C, HVC-320W-428A,B,C

A-Adjustable potentiometer version B-Three-in-one dimming version C-12V auxiliary power version

Descrição do produto

HVC 320W LED Driver Parameters

Input voltage: 100-277V (Wide Input Voltage) Output voltage: 27-56V/214-428V Rated power: 320W Electrical performance parameters: THD＜10%/PF＞0.95

Features of HVC 320W LED Driver

Class I type for insulation Isolated flicker free LED driver Constant current output ,with power limitation for control mode Surge: 6/10KV Metal material case, protection grade against water and dust: IP67 Protection: SCP/OVP/OTP Global certifications: ENEC/CE/CCC/CB(C version is compliant with new ERP directive)

Dimming function: Three-in-one dimming (resistance dimming, 1-10V dimming, PWM dimming) and 12V/0.25A auxiliary power

Warranty: 5 years

Applications of HVC 320W LED Driver

Street lighting, industrial lighting, stadium lighting, landscape lighting, plant lighting and other lighting lamps.

Model list

Model	Rated Power	Input Voltage	Output Voltage	Outpot Current	Product Size	THD.(Typ)	Pf.(Typ)
HVC-320W-56A	320W	100-277V	27-56V	4200-7650mA	2528944mm	<10%	>0,95
HVC-320W-56B	320W	100-277V	27-56V	4200-7650mA	2528944mm	<10%	>0,95
HVC-320W-56C	320W	100-277V	27-56V	4200-7650mA	2528944mm	<10%	>0,95
HVC-320W-428A	320W	100-277V	214-428V	500-1050mA	2528944mm	<10%	>0,95
HVC-320W-428B	320W	100-277V	214-428V	500-1050mA	2528944mm	<10%	>0,95
HVC-320W-428C	320W	100-277V	214-428V	500-1050mA	2528944mm	<10%	>0,95

HVC-320W-XXX

More HVC product specifications
