Input voltage range: 100-277V Output voltage: 180-260V

Rated power: 120W

THD＜10%/PF＞0.95

Class I type for insulation Constant current output , with power limitation for control mode, non-isolated, flicker free

Dimmable constant current led driver Efficiency up to 94%（Typ.）

Surge protection: 6/10KV

Metal material case, IP67 Protections: SCP/OTP/OVP Certifications: CCC/CE/CB (C version is compliant with the new ERP standard) Dimming function: 3 in 1 dimming(1-10V dimming/PWM dimming/resistance dimming), 12/0.25A AUX power

Output current is dimmed by external potentiometer (Only Type A) Output current is dimmed by Isolated 3 in 1 dimmer（Only Type B） Output current dimmed by isolated 3-in-1 dimmer +12V auxiliary power output（Only Type C）

Working temperature: -40 ~ 55℃ Safety case temperature: -40 ~ 90℃ Storage temperature: -40 ~ 80℃ Warranty: 5 years

Application Street lighting, industrial lighting, stadium lighting, floodlight lighting, landscape lighting , plant lighting

Model	Rated Power	Input Voltage	Output Voltage	Outpot Current	Product Size	THD.(Typ)	PF.(Typ)
HVS-120W-260A	120W	100-277V	180-260V	300-600mA	145*56*32mm	<10%	>0.95
HVS-120W-260B		100-277V	180-260V	300-600mA	145*56*32mm	<10%	>0.95
HVS-120W-260C		100-277V	180-260V	300-600mA	145*56*32mm	<10%	>0.95
